WAF 指纹识别原理与实现：从 sqlmap 源码学起

WAF（Web Application Firewall）是渗透测试的第一道坎。扫之前先搞清楚对面是什么 WAF——Cloudflare？阿里云 WAF？安全狗？不同 WAF 的绕过策略天差地别。这篇从 sqlmap 的 WAF 检测模块拆解指纹识别的底层原理。

WAF 指纹识别的两种思路

主动探测：发送特定 Payload，根据响应特征判断。sqlmap 用的就是这招。
被动识别：看响应头里的 Server、X-Powered-By，或者 Cookie 里 WAF 注入的标记。

vibeWaf 结合了两种思路——先被动扫一眼，不命中再主动发 Payload。

被动识别：响应头里的证据

很多 WAF 会在响应中留下痕迹：

PASSIVE_FINGERPRINTS = {
    'Cloudflare': {
        'headers': {
            'Server': r'cloudflare',
            'CF-Ray': r'.+',
        },
    },
    'Aliyun WAF': {
        'headers': {
            'Server': r'ALB|AliyunOSS',
            'X-Security-Token': r'.+',
        },
        'cookies': ['aliyungf_tc'],
    },
    'Safedog': {
        'headers': {
            'X-Powered-By': r'WAF/\d+\.\d+',
        },
        'cookies': ['Safedog-Flow-Plugin'],
    },
    'Tencent Cloud WAF': {
        'body': [
            r'腾讯云 WAF',
            r'stgw_403_forbidden',
        ],
    },
    'Baidu Yunjiasu': {
        'headers': {
            'Server': r'yunjiasu',
            'X-Server': r'yunjiasu',
        },
    },
}

def passive_detect(target_url, session):
    """被动识别 WAF"""
    try:
        resp = session.get(target_url, timeout=10)

        for waf_name, fingerprint in PASSIVE_FINGERPRINTS.items():
            score = 0

            # 检查响应头
            for header, pattern in fingerprint.get('headers', {}).items():
                value = resp.headers.get(header, '')
                if re.search(pattern, value, re.IGNORECASE):
                    score += 1

            # 检查 Cookie
            for cookie_name in fingerprint.get('cookies', []):
                if cookie_name in resp.cookies:
                    score += 1

            # 检查页面内容
            for pattern in fingerprint.get('body', []):
                if re.search(pattern, resp.text[:5000], re.IGNORECASE):
                    score += 1

            if score >= 2:
                return {'waf': waf_name, 'method': 'passive', 'confidence': 'high'}

    except Exception as e:
        pass

    return None

主动探测：从 sqlmap 学攻击性检测

sqlmap 的 WAF 检测逻辑在 lib/request/connect.py 中。核心思路很简单：

发送一个显然恶意的 Payload → 看响应是否被拦截 → 根据拦截页面的特征判断 WAF 类型

import hashlib

# 构造一个明显恶意的请求
# ?id=1 AND 1=1 UNION SELECT ... → 正常 WAF 都会拦截
MALICIOUS_PAYLOAD = (
    "%d' AND %d=%d UNION ALL SELECT NULL,NULL,NULL,NULL,"
    "NULL-- " + hashlib.md5(b"waf_test").hexdigest()
)

def active_detect(target_url, session):
    """主动探测 WAF 类型"""
    # 1. 发送正常请求获取基线
    baseline = session.get(target_url, timeout=10)
    baseline_status = baseline.status_code
    baseline_length = len(baseline.text)

    # 2. 发送恶意 Payload
    test_url = f"{target_url}?id={MALICIOUS_PAYLOAD}"
    try:
        response = session.get(test_url, timeout=10)
    except requests.exceptions.ConnectionError:
        return {'waf': 'Unknown', 'method': 'active', 'note': '连接被重置（可能被 WAF 阻断）'}

    # 3. 对比响应差异
    status_changed = response.status_code != baseline_status
    length_changed = abs(len(response.text) - baseline_length) > 200
    content_contains_block = any(
        w in response.text.lower()
        for w in ['blocked', 'forbidden', 'waf', '防火墙', '拦截']
    )

    if not (status_changed or length_changed or content_contains_block):
        return None  # 可能没有 WAF

    # 4. 根据响应特征识别 WAF 类型
    return identify_waf_by_response(response)

WAF 指纹规则库

这是 vibeWaf 的核心——一个包含 60+ 条 WAF 指纹规则的 JSON 数据库：

{
  "wafs": [
    {
      "name": "Cloudflare",
      "detection": [
        {
          "type": "status",
          "value": 403
        },
        {
          "type": "header",
          "name": "Server",
          "pattern": "cloudflare"
        },
        {
          "type": "body",
          "pattern": "Cloudflare Ray ID: [0-9a-f]{16}"
        },
        {
          "type": "body",
          "pattern": "Attention Required! \\| Cloudflare"
        }
      ]
    },
    {
      "name": "ModSecurity",
      "detection": [
        {
          "type": "status",
          "value": 403
        },
        {
          "type": "body",
          "pattern": "ModSecurity|mod_security|This error was generated by Mod_Security"
        },
        {
          "type": "body",
          "pattern": "rules of the requested resource"
        }
      ]
    },
    {
      "name": "阿里云 WAF",
      "detection": [
        {
          "type": "body",
          "pattern": "阿里云 Web应用防火墙|Aliyun Web Application Firewall"
        },
        {
          "type": "status",
          "value": 405
        }
      ]
    },
    {
      "name": "安全狗",
      "detection": [
        {
          "type": "header",
          "name": "X-Powered-By",
          "pattern": "WAF"
        },
        {
          "type": "body",
          "pattern": "Safedog|安全狗|safedog"
        }
      ]
    },
    {
      "name": "D盾",
      "detection": [
        {
          "type": "body",
          "pattern": "D盾|D盾_防火墙|D-Security"
        },
        {
          "type": "status",
          "value": 403
        }
      ]
    }
  ]
}

每条规则包含多个检测维度（status + header + body），全部命中才判定为该 WAF，降低误报。

检测引擎实现

import json
import re

class WafDetector:
    def __init__(self, rules_file='data.json'):
        with open(rules_file, 'r', encoding='utf-8') as f:
            self.rules = json.load(f)

    def detect(self, response):
        """根据 HTTP 响应识别 WAF 类型"""
        results = []

        for waf in self.rules['wafs']:
            name = waf['name']
            detections = waf['detection']
            matched = 0

            for rule in detections:
                if rule['type'] == 'status':
                    if response.status_code == rule['value']:
                        matched += 1

                elif rule['type'] == 'header':
                    header_val = response.headers.get(rule['name'], '')
                    if re.search(rule['pattern'], header_val, re.IGNORECASE):
                        matched += 1

                elif rule['type'] == 'body':
                    if re.search(rule['pattern'], response.text, re.IGNORECASE):
                        matched += 1

            # 所有检测规则都命中才算匹配
            if matched == len(detections):
                results.append({'waf': name, 'confidence': 'high'})

        return results

绕过策略速查表

识别了 WAF 类型，绕过策略就有方向了：

WAF	弱项	绕过 Payload 示例
Cloudflare	分块传输编码	`Transfer-Encoding: chunked`
ModSecurity	参数污染	`?id=1&id=1' OR '1'='1`
阿里云 WAF	大小写混写	`SeLeCt * FrOm users`
安全狗	内联注释	`/!50000UNION/ SELECT`
360 主机卫士	HTTP/0.9	使用 HTTP/0.9 协议
D盾	特殊字符编码	`%2527` (双重 URL 编码)

实现中的细节

1. sqlmap 的 Payload 为什么用 MD5

1	payload = f"%d' AND %d=%d UNION ALL SELECT NULL... -- {md5('waf_test')}"

md5 字符串有两个作用：

唯一标识：如果响应中出现这个 md5，说明 Payload 未被执行（被 WAF 拦截了），但如果 WAF 拦截后返回了原始请求内容，这个 md5 也会出现。通过对比正常请求和恶意请求的响应差异来判断。
避免缓存：每次测试生成新的 Payload，绕过 CDN 缓存。

2. 多 Payload 确认

不要用一个 Payload 就下结论。至少发 2-3 个不同类型的恶意请求交叉验证：

PAYLOADS = [
    "1' AND '1'='1",             # SQL 注入
    "<script>alert(1)</script>", # XSS
    "../../../etc/passwd",       # 路径穿越
]

def multi_payload_verify(target_url, session):
    """多 Payload 交叉验证 WAF 存在性"""
    baseline = session.get(target_url)

    blocks = 0
    for payload in PAYLOADS:
        resp = session.get(f"{target_url}?q={payload}")
        if resp.status_code == 403 or len(resp.text) < len(baseline.text) * 0.3:
            blocks += 1

    return blocks / len(PAYLOADS)  # 拦截率

总结

WAF 指纹识别本质上是一个模式匹配问题。被动识别看响应头和 Cookie，主动探测发送恶意 Payload 看反应。sqlmap 的思路很经典——用一个明显恶意的请求试探，根据 WAF 的拦截页面特征反推类型。

知道对面是什么 WAF，后面的绕过才有方向。
